    • Blue Sea m-Series Mini Dual Circuit Plus Battery Switch

    Blue Sea m-Series Mini Dual Circuit Plus Battery Switch
    $82.92
    Simultaneously switches two isolated battery banks or combines battery banks to all loads View full description

    This item and any accompanying items are for in-store pickup only.
    Separate orders or contact us at online@trotac.ca
    for special shipping arrangements.

    Simultaneously switches two isolated battery banks or combines battery banks to all loads

    • Make before break contact design allows switching between battery banks without power interruption

    Specifications

    Switch Type Dual Circuit Plus
    Color Red, Black
    Switch Positions 3
    Battery Combine Yes
    Alternator Field Disconnect No
    Maximum Voltage 32V DC
    Stud Size 3/8"
    Terminal Stud Torque 120 in-lb (13.56 Nm)
    Continuous Rating 300A
    Intermittent Rating 450A (5 min)
    Cranking Rating 30 sec 675A per circuit
    Battery Inputs 2
    Cable Clearance For 4/0 AWG Cables 1.12in (28.45 mm)
    Cable Size to Meet Ratings 4/0 AWG (120mm²)
    Mounting Holes Accept #10 Screw
    Stud Material Tinned Copper
    Stud Torque 120 in-lb (13.56 Nm)
    Terminal Stud Size 3/8" - 16 (M10)
    Weight 0.80lb (0.36 kg)
    Weight 0.80lb (0.36 kg)
    Brand:
    Blue Sea Systems
