Blue Sea 8252 DC Ammeter - 50-0-50A with Shunt

SKU:
BSS8252
$133.72
Backlit meter face (separate 12 or 24V DC backlight connections) View full description
  • Meters read both discharge and charge current
  • Simple 4-wire connection from shunt
  • Meter senses and powers from shunt connection
  • Includes appropriate DC shunt
  • Backlit meter face (separate 12 or 24V DC backlight connections)
Specifications
MeterCurrent
Face Size2.75in (69.85 mm)
Function50 to 50A
Backlighting Amperage16mA @ 12V DC
20mA @ 24V DC
Meter Current1mA at full scale
Shunt TypeExternal 50mV@full scale
Weight0.54lb (0.24 kg)
Weight0.58lb (0.26 kg)
Brand:
Blue Sea Systems
